CLARACOUSTICS
HANDCRAFTED ACOUSTIC PANELS — MATOSINHOS (PORTUGAL)
FROM GENERAL ROOM TREATMENT AND NOISE REDUCTION TO MORE DEMANDING PRO APPLICATIONS WHERE CRITICAL LISTENING IS THE GOAL, WE OFFER EFFICIENT & COST-EFFECTIVE SOLUTIONS FOR EACH USE CASE.
APPLICATIONS: RECORDING STUDIOS/ MIXING & MASTERING ROOMS/ VOCAL & ISO BOOTHS/ REHEARSAL SPACES/ HOME THEATRES/ CLASSROOMS/ CO-WORKING SPACES/ OFFICES/ MEETING ROOMS/ CAFETERIAS/ GYMS & more.
ACOUSTIC PANELS
Wide-Line
Designed for high-impact acoustic treatment where maximum surface area is available. The 78cm width allows for efficient coverage of large wall sections, live rooms, and co-working spaces.
Performance Note: Absorption is determined by thickness. All models below share identical NRC and frequency ratings for their respective depth.
All CLARACOUSTICS panels are manufactured to order in our workshop with great care and attention to detail.
Each unit is assembled by hand using a solid wood frame and PN70 Rockwool (70 kg/m³), selected for its optimal absorption characteristics.
We offer five standard colours: Natural Burlap, Black, Dark Blue, Wine Red, and Rat Grey.
OUR CURRENT ACOUSTIC PANELS RANGE CONSISTS OF 47 MODELS, DIVIDED INTO THREE (3) LINES, FOUR (4) THICKNESS & SIX (6) HEIGHT OPTIONS:
WIDTH (enhanced coverage for larger spaces or other specific use cases)
WIDE-LINE (78cm wide)
STANDARD LINE (63cm wide)
THIN-LINE (33cm wide)
THICKNESS (panel performance is strictly defined by thickness - please refer to the knowledge base section below for additional info)
BROADBAND 50 (BB 50): Single slab (5cm). General mid-to-high frequency absorption for noise reduction and echo control.
BROADBAND 100 (BB 100): Double slab (10cm). Enhanced mid-frequency absorption for general treatment and larger spaces.
BROADBAND 150 (BB 150): Triple slab (15cm). Engineered for low to low-mid frequency control and bass trapping.
BASS TRAP 200 (BT 200): Quadruple slab (20cm). Ultimate low-frequency absorption and bass trapping.
Designed for critical listening environments, sub-bass trapping, and eliminating room modes below 100 Hz.
HEIGHT (flexible options that cover most rooms dimensions)
TALL (186cm)
STANDARD PLUS (143cm)
STANDARD (124,5cm)
COMPACT (94,5cm)
MINI PLUS (78cm)
MINI (63cm)
Standard Line
The versatile core and probably best selling line in our range. Available in five distinct sizes to fit various room configurations and wall spaces while maintaining the standard 63cm width profile.
Application: Ideal for home studios, control rooms, and office/meeting spaces where wall space is limited but performance is critical.
Thin-Line
Narrow design for spaces where every centimeter counts. At only 33cm wide, these panels fit into tight corners, narrow wall strips, and residential spaces without compromising on aesthetic.
Best For: Narrow walls, hallways, or residential spaces, and reflection point treatment or wall-to-wall & wall-to-ceiling corners in smaller rooms.
Unsure about which PANELS to buy? Send us your room dimensions and a photo.
We provide free acoustic advice to help you choose the exact layout and panel thickness for your room.
NRC 0.45 | Flush: >1000 Hz | Air Gap: >600 Hz | Single slab → 5cm
NRC 0.80 | Flush: >500 Hz | Air Gap: >250 Hz | Double slab → 10cm
NRC 0.95 | Flush: >300 Hz | Air Gap: >125 Hz | Triple slab → 15cm
NRC 1.00 | Flush: >200 Hz | Air Gap: >80 Hz | Quadruple slab → 20cm
All CLARACOUSTICS panels are manufactured to order in our workshop with great care and attention to detail.
Each unit is assembled by hand using a solid wood frame and PN70 Rockwool (70 kg/m³), selected for its optimal absorption characteristics.
We offer five standard colours: Natural Burlap, Black, Dark Blue, Wine Red, and Rat Grey.
OUR CURRENT ACOUSTIC PANELS RANGE CONSISTS OF 47 MODELS, DIVIDED INTO THREE (3) LINES, FOUR (4) THICKNESS & SIX (6) HEIGHT OPTIONS:
WIDTH (enhanced coverage for larger spaces or other specific use cases)
WIDE-LINE (78cm wide)
STANDARD LINE (63cm wide)
THIN-LINE (33cm wide)
THICKNESS (panel performance is strictly defined by thickness - please refer to the knowledge base section below for additional info)
BROADBAND 50 (BB 50): Single slab (5cm). General mid-to-high frequency absorption for noise reduction and echo control.
BROADBAND 100 (BB 100): Double slab (10cm). Enhanced mid-frequency absorption for general treatment and larger spaces.
BROADBAND 150 (BB 150): Triple slab (15cm). Engineered for low to low-mid frequency control and bass trapping.
BASS TRAP 200 (BT 200): Quadruple slab (20cm). Ultimate low-frequency absorption and bass trapping.
Designed for critical listening environments, sub-bass trapping, and eliminating room modes below 100 Hz.
HEIGHT (flexible options that cover most rooms dimensions)
TALL (186cm)
STANDARD PLUS (143cm)
STANDARD (124,5cm)
COMPACT (94,5cm)
MINI PLUS (78cm)
MINI (63cm)
PRO TIP
Size determines how much wall space you cover.
Thickness (5/10/15/20 cm) determines which frequencies the panel can absorb.
Choose thickness based on your acoustic problems AND size based on your wall space.
ROOM KITS
CLARACOUSTICS ROOM KIT CALCULATOR
1. Room Dimensions (meters)
2. Obstructions
3. Build Your Kit
Room Visualization
Kit Summary
Add panels to see recommendations based on your room size.
The "Voice-Over" Kit (Vocal Booth)
Target: Podcasters, Voice Actors.
Contents: 4x Mini Plus 50 (Corners/Walls) + 2x Mini Plus 100 (Rear Wall).
Price: ~€350 (inc VAT)
The "Bedroom Producer" Kit (Home Studio - Entry)
Target: Beatmakers, Hobbyists.
Contents: 6x Standard 100 (Reflections) + 4x Standard 150 (Corners).
Price: ~€950 (inc VAT).
The "Audiophile" Kit (Listening Room - Mid)
Target: Hi-Fi enthusiasts.
Contents: 4x SlimFit 100 (Side walls) + 4x SlimFit 150 (Rear/Corners).
Price: ~€850 (inc VAT).
The "Podcast HQ" Kit (Office/Meeting)
Target: Multi-person recording, Zoom calls.
Contents: 10x Wide-Line 50 (Maximum coverage for echo).
Price: ~€600 (inc VAT).
The "Mix Engineer" Kit (Home Studio - Pro)
Target: Serious mixing, Mastering.
Contents: 8x Standard 100 + 8x BassTrap 200 (Full Bass Trapping).
Price: ~€1,800 (inc VAT).
The "Reference" Kit (Listening Room - High)
Target: High-end systems, Critical listening.
Contents: 6x SlimFit 150 + 4x BassTrap 200 (Deep control).
Price: ~€1,400 (inc VAT).
Custom sizes and/or colours available through our CUSTOM SHOP.
*Additional fees apply and longer manufacturing times are to be expected for all custom orders..
TECH & DATA
Why PANEL Thickness Dictates Performance (Not Width)?
This is the most critical concept in acoustic treatment. Absorption is determined by depth, not surface area.
High Frequencies (Treble): Small, fast waves. They are easily caught and absorbed by the first few centimetres of porous material (like the 5cm panels).
Low Frequencies (Bass): Massive, long waves. They require depth to be absorbed. A bass wave must travel deep into the material, rubbing against the fibres to lose its energy (converting sound into heat).
Whether the panel is 78, 63 or 33cm wide, the depth the sound wave travels into the material is identical if the thickness is the same.
Width determines how much wall space you cover with that performance.
Thickness determines how low in frequency you can absorb.
So in practice, a wider panel treats a larger area faster, but it doesn’t reach lower frequencies than a narrow panel of the same depth.
GENERAL SPACES / OFFICE / CLASSROOM
PRO RECORDING STUDIO / CONTROL ROOM
BASS TRAPPING (Corners)
NARROW WALLS / HALLWAYS
STANDARD LINE
WIDE-LINE
150 / 200mm (any line)
THIN-LINE
Good balance of coverage and aesthetics; breaks up reflections without looking like a studio.
Maximizes low-mid absorption, minimizes edge diffraction, reduces installation time, ensures continuous coverage.
whY CHOOSE larger panels OVER smaller/cheaper models?
This question gets to the heart of practical acoustic design. If performance per square meter is identical for Mini (63x63 cm) or Tall Wide (186x78 cm) panels of the same thickness, why choose fewer larger models over multiple smaller panels? Beyond simple wall coverage speed and surface area, larger panels offer distinct acoustic and practical advantages that smaller panels cannot replicate, even if you use enough small ones to cover the same total area.
-
Sound waves, especially lower mid-frequencies, behave like water flowing around a rock.
Small Panels: A 63x63 cm panel has a high ratio of "edge" to "surface." Sound waves can easily diffract (bend) around the small edges, bypassing the absorption material entirely. This reduces the effective absorption area, particularly for frequencies near the panel's cutoff point.
Large Panels: A 186x78 cm panel has a much larger central "core" area where the sound wave hits the material directly without being influenced by the edges. This ensures the theoretical performance (the NRC and frequency numbers) is actually achieved in the real world. Large panels act as a more solid "barrier" to sound energy.
-
Low-frequency sound waves are long (a 100 Hz wave is over 3 meters long).
Small Panels: To a long bass wave, a small 60 cm panel looks like a tiny speck. The wave largely ignores it, passing around it with minimal interaction. You would need a dense grid of small panels to trick the bass wave into interacting with the treatment.
Large Panels: A tall, wide panel presents a significant physical obstacle to long waves. It intercepts a larger portion of the wavefront, forcing more energy into the material. This makes large panels disproportionately more effective for low-mid frequencies (100–250 Hz) than an equivalent area of small scattered panels.
-
Mounting Points: Covering 4 m² with Mini panels might require 10+ individual mounting points, precise spacing calculations, and hours of labor to ensure they look intentional. Covering the same area with our Tall Wide panels might require only 3 or 4 units, drastically reducing installation time and potential failure points.
Visual Coherence: In professional studios or modern offices, a "grid" of many small squares can look cluttered or dated. Large panels offer a sleek, minimalist aesthetic that integrates better with architecture. They allow for creative arrangements (e.g., a single vertical column of tall panels) that small squares cannot achieve.
-
Gaps Matter: When you install multiple small panels, you inevitably have gaps between them. While some diffusion is good, large gaps can allow sound to reflect off the untreated wall between panels, creating a "comb filtering" effect (a hollow, metallic sound).
Seamless Treatment: Larger panels minimize these gaps. When placed edge-to-edge, they create a near-continuous absorptive surface, which is critical for control rooms or recording booths where you want to eliminate all wall reflections, not just reduce them.
Physical depth constraint is the priority; performance is maintained via thickness.
If the goal is critical listening (mixing, mastering, high-end home theatre), thicker medium-to-large panels are superior because they manage low-mid frequencies more effectively and reduce edge diffraction.
If the goal is general noise reduction (classroom speech intelligibility, making a busy office quieter, reducing echo in a gym), thinner small-to-medium size panels are often sufficient and more cost-effective.
Thickness matters most here, but larger widths (Wide-Line) cover more of the corner triad effectively.
Technical Insight: The Power of the Air Gap
Why does leaving a space behind the panel improve bass absorption?
-
Imagine sound waves as ocean waves hitting a sea wall. When the panel is mounted flush directly to the wall, the "wave" hits the surface and bounces back almost immediately. It only interacts with the very front of the material. This works great for small, fast waves (high notes), but the big, slow waves (bass) pass right through or bounce off before they can be absorbed.
-
When you mount the panel 5–10 cm away from the wall, you create a "trampoline" effect. The sound wave passes through the fabric, travels through the wool, crosses the air gap, hits the wall and then reflects back into the wool.
This effectively doubles the distance the sound wave travels through the absorbing material.
It creates a zone of maximum friction right at the air gap, where the sound wave slows down the most.
A 5 cm panel with an air gap acts like a 10 cm panel. A 15 cm panel with an air gap becomes a powerhouse for deep bass, reaching frequencies as low as 125 Hz (the rumble of a kick drum or bass guitar).
Simple Rule: If you need to control bass or make a room sound "tighter," always mount your panels with an air gap.
SCENARIO
TIGHT BUDGET / DIY
MINI / MINI + / COMPACT
RECOMMENDATION
WHY ?
Cheaper per unit, easier to transport/handle alone, flexible placement.
Frequently Asked Questions
-
The three lines exist to solve architectural constraints, not acoustic ones.
Wide-Line: Best for large studios or halls where you need to cover big walls quickly with fewer mounting points.
Standard-Line: The perfect balance for most home theaters, offices, and classrooms.
Thin-Line: Designed for narrow walls, hallways, or residential spaces where a wide panel would stick out too far or look out of place.
The Science: A 10 cm thick panel absorbs the exact same frequencies whether it is 78 or 33 cm wide. The difference is purely aesthetic and logistical.
-
Thickness is king. While the width and height of a panel determine how much wall space you cover, the thickness (5 cm, 10 cm, 15 cm, or 20 cm) determines which frequencies the panel can absorb.
Thin panels (5 cm) are great for reducing echo and clarifying speech (high frequencies).
Intermediate thickness panels (10 cm) offer balanced results around the mid frequency range.
Thick panels (15–20 cm) are required to absorb bass and low-mid frequencies.
Expert Note: A narrow 20cm thick panel will absorb deeper bass than a wide 5cm thick panel.
Always choose thickness based on your acoustic problems, and panel size (height & width) based on your available wall space. -
For large spaces where the goal is reducing general noise levels and speech intelligibility (rather than critical bass trapping), you prioritize coverage.
Recommendation: Our Wide-Line (5 cm or 10 cm) is ideal here. The larger surface area allows you to treat significant wall space with fewer units, reducing installation time and cost.
Mounting: In these environments, flush mounting is often sufficient since bass control is less critical than in a music studio. The 10 cm thickness offers a great balance of performance and profile for these spaces.
-
You need depth. Standard thin foam or 5 cm panels are excellent for clarifying speech and reducing high-frequency echo (like in an office or classroom) but they will do almost nothing for bass.
Recommendation: Choose our 150 mm (15 cm) or 200 mm (20 cm) models.
Placement: Install them in room corners (where bass builds up) or on the walls behind your speakers/subwoofer.
Pro Tip: Mount them with an air gap for maximum low-frequency control. The 20cm model is specifically engineered for "sub-bass trapping" application.
-
Acoustic foam is porous and lightweight, making it effective only for very high frequencies (hiss and snap). It is transparent to bass.
Our Choice: We use PN70 Rockwool, a dense mineral wool. Density is critical for creating the friction needed to stop low-frequency sound waves.
Durability: Unlike foam, which can degrade and turn to dust over time, Rockwool maintains its performance indefinitely.
Safety: Our panels are wrapped in breathable, acoustically transparent fabric that contains the fibers completely, making them safe for homes and studios.
-
The 200mm (20 cm) model is our "ultimate" solution for critical listening environments.
Performance: While the 150mm model absorbs down to ~125 Hz (with an air gap), the 200mm model pushes this boundary down to ~80 Hz.
Application: This extra 5 cm makes a massive difference for sub-bass (the rumble of kick drums, bass guitars, and synths). If you are building a mastering suite, a high-end home theater, or struggling with room modes below 100 Hz, the 200 mm model is the definitive fix.
-
NRC (Noise Reduction Coefficient) is the industry standard rating for how much sound a material absorbs, rated from 0.00 (reflects everything) to 1.00 (absorbs everything).
5 cm panels: NRC ~0.45 (Good for speech clarity).
10 cm panels: NRC ~0.80 (Excellent all-rounders).
15 cm & 20 cm panels: NRC 0.95 – 1.00 (Near-perfect absorption, especially with an air gap).
Note: Our ratings are based on high-density PN70 Rockwool (70 kg/m³). Cheaper panels often use lower density wool, which significantly reduces performance, especially in the bass range.
-
Mounting a panel with an air gap (leaving 5–10 cm of empty space between the panel and the wall) is the single most effective way to boost bass absorption without buying thicker panels.
How it works: The gap allows the sound wave to pass through the panel, hit the wall, and reflect back through the panel. This effectively doubles the distance the sound travels through the absorbing material.
The Result: A 5 cm panel with an air gap performs like a 10 cm flush-mounted panel. For our 200mm thick models, an air gap unlocks sub-bass absorption down to 80 Hz, making them powerful bass traps.
Simple Rule: If you want your mixes to sound tighter and your bass clearer, always mount with an air gap.
-
It depends on your goal:
Echo Reduction (Offices/Classrooms): Cover 15–20% of the wall surface with 5 cm or 10 cm panels.
Critical Listening (Studios/Home Theater): You need a mix. Start with 10 cm or 15 cm panels on reflection points (side walls, ceiling), and add 20 cm panels in corners for bass trapping. Aim to treat about 30–40% of the surface area.
Unsure? Send us your room dimensions and a photo. We provide free acoustic advice to help you calculate the exact layout and thickness required.
-
Yes! Custom sizes and/or colours are available through our CUSTOM SHOP. We can manufacture 100% bespoke solutions for clients who need them. We’ll work closely with you by meticulously and carefully planning your room design so that it suits your day-to-day workflow and room architecture.
*Please note: Additional fees apply either on a per panel or per order basis, and longer manufacturing times are to be expected for all custom orders. -
You can absolutely install them yourself. We design them for DIY flexibility.
Flush Mount: Simple sawtooth hangers or impaling clips directly to the wall.
Air Gap Mount: Use simple wood battens or specialized acoustic brackets to hold the panel 5–10 cm off the wall.
Heavy Panels: For our larger 150 mm and 200 mm models, we recommend using sturdy impaling clips or a French cleat system to ensure they are securely anchored, as they are heavier than standard thin panels.
-
ORDERS: Get in touch anytime either to order or get help selecting the products you need. After product selection and budget approval, we’ll finish up the remaining details and give you an approximate date when your order is ready for pickup.
STOCKS: We try to have a few items in stock of our best selling panels, which you can pickup immediately however, this is not always possible due to workload constraints. Occasionally we may have some B-STOCK inventory (either one-off Room KITS or stand-alone panels) at reduced prices.
DELIVERY TIMES: Manufacturing times may vary but small to mid-sized orders are usually fulfilled in 1-2weeks or less. For bigger orders we’ll give clients an estimate deadline based on current workload, our supply chains and other client orders still in production to be fulfilled.
INSTALLATION: At the moment, we don’t install, ship or deliver any products. Working to secure contracts with reliable delivery/shipping partners asap.
PICKUP: Order can be picked up at our HQ in South Matosinhos. Details will be provided with your order.
PAYMENT: We charge 50% upfront to secure orders and the remaining 50% are paid at pickup. Upfront payment is non-refundable. Canceled orders -
FREEACOUSTIC ADVICE Having one of the most complete product ranges you’ll find, size-wise, these options allows us to easily deal with most situations. We know that sometimes it can be hard to figure out how to properly treat a room so we provide free acoustic advice to help our clients with the exact room layout and best panel models & thickness options for their space and intended use case.
PANEL SIZES: We have a pretty big range of panels sizes for maximum installation flexibility in many different use cases. They are available in 3 width (Wide, Standard, Thin), 4 thickness (5, 10, 15, 20cm) and 6 different height options (from 63 to 186cm), for a total of 48 panel models.
PANEL COLOURS: We offer 5 standard colours — Natural Burlap, Black, Dark Blue, Wine Red, and Rat Grey. These may vary slightly per each batch order, except Natural Burlap which is pretty much the same every time we re-stock. Other options are only available via our CUSTOM SHOP orders.
Unsure about which PANELS to buy? → Send us your room dimensions and a photo. We’re glad to point you in the right direction.
BESPOKE ROOM DESIGN → We offer a bespoke room design service when a personalised approach to room design is needed. It usually involves taking acoustical measurements, followed by careful planning, working closely with each client to achieve the best results.
handcrafted acoustic panels MANUFACTURER — Matosinhos (PORTUGAL)
CLARACOUSTICS
High-density PN70 Rockwool panels for studios, rehearsal spaces and more.
📞 +351 965 054 641
ENQUIRIES & ORDERS →
© 2026 CLARACOUSTICS
